Order in Pubsub, is it a big deal?

Order in Pubsub, is it a big deal?

February 14, 2020

When talking to clients, the topic of message ordering came up a few times when talking about GCP Pub/Sub or event architecture cornerstones like it. When looking at the architecture, it becomes clear, Pub/Sub can have ordering issues, since it contains N publishing forwarders and M subscribing forwarders, depending on the ingress and egress load. But that doesn’t mean that messages will always be out of order. Often, messages may come in at a rate as low as 1 msg per second. Will it be out of order then? Or maybe at a rate of 10 msg/sec? Or 50? Of course this depends on many factors (such as message size and sender count / geographical location). But assuming we have 1 sender and 1 receiver, when will PubSub start showing out of order messages?

pubsub architecture

To me, this sounds like a perfect question to run a little experiment.

Experimental setup

Every hour, a cloud scheduler event triggers a cloud function
the function sends messages to pubsub for 10 minutes sequentially with a pause interval of [1sec;1/2th sec; 1/10th sec;... 1/100 sec]
- each message contains a continuous counter
- a total of about up to 9000 msgs is sent per run
Pub Sub push forwards these messages to an AppEngine deployment
AppEngine keeps track of the messages coming in and compares the previous message counter and the current messages’ counter. If it isn’t continuous, it logs an out-of-order message. If the message isn’t in “it’s right place” (meaning message with counter 100 is the 100th message received), an out-of-index is logged.
Because AppEngine is stateless, all results are stored in a basic memorystore instance

Code

All code is available on Github.

To set up the infrastructure, I used terraform. To deploy the AppEngine code as well as the cloud function code I use the archive_file provider in terraform together with uploading the source code to Google Cloud Storage as a zip file. Versioning of the applications is handled by GCP. Unfortunately, the google provider doesn’t support the vpc_access_connector property required to get AppEngine to connect to Memory store. So that one has to be manually deployed with gcloud despite terraform being able to handle the deployment for me.

All files are shown below. It’s actually not much. The infra folder is artificially blown up due to what I’m used to from projects at clients. Most files contain only 1-2 resource definitions.

$ tree -L 2 ./
./
├── generator
│   ├── main.py
│   ├── requirements.txt
│   └── test_main.py
├── infra
│   ├── account.json
│   ├── apis
│   ├── appengine.tf
│   ├── bucket.tf
│   ├── function.tf
│   ├── provider.tf
│   ├── pubsub.tf
│   ├── redis.tf
│   ├── scheduler.tf
│   └── variables.tf
├── reader
│   ├── app.yaml
│   ├── main.py
│   ├── requirements.txt
│   ├── test_main.py
│   └── test_request.json
└── README.md

Sidenote: GCP requires each API to be enabled before you can create resources. I created an API module but it’s best to have a separate TF project for this. This could be called the “bootstrapping” project, which is run under org admin priviliges and creates the target project as well as all APIs needed for the given project. It could then also create the key for the service account that can be used by the project specific terraform setup. Ideally, that service account is stored in a secrets store and terraform apply is only executed through CICD.

Sender

Below is the core routine of the sender.

counter = 1
print(f"stage {stage}, sending message every 1/{nth} second")
finish_time = datetime.now() + duration
while datetime.now() < finish_time:
    _send(publisher, _make_message(stage, nth, counter))
    counter += 1
    time.sleep(1 / nth)

the hour mappings are

hour_mapping = {
0.5,
1,
2,
10,
50,
100,
}

meaning that stage 0 sends 1 msg every 2 seconds, stage 3 10 msg/sec and stage 5 100msg/sec.

Receiver

The core flow of the receiver is to simply keep a tally of the out of order and out of index messages. Because AppEngine doesn’t keep state reliably, I use Cloud Memory Store (Redis) to keep state. I set the AppEngine auto-scaling to manual and 1 instance to avoid out-of-order errors due to my own infrastructure. The downside here is that a single AppEngine instance probably cannot handle HTTP requests as quickly as PubSub can send them.

def _handle_step(msg):
    msg_counter = msg["counter"]
    id = _id_key(msg["stage"])

    #set new state values
    max = _set_max(msg_counter, id)
    db_total = r.incr(total_key.format(id))
    db_last  = r.getset(last_key.format(id), msg_counter)
    db_last = 0 if db_last is None else int(db_last)

    # log simple hist view
    _log_hist(id, db_total, db_last, msg_counter)
    _log_offs(id, max, msg_counter)

Results

Because analyzing the results through logging outputs can be a bit annoying (and more importantly because I’m not currently in the mod of making fancy visuals), I made use of a simple string to quickly visualize out of order events. So for an example of a 1/50th sec message flow, the following results can be observed:

Note:

I: out of index
O: out of order (4 didn’t follow 5)
.: All went well, right order, right index

  "20200217-12:0.hist": ".........................................................................................................................................................................................................................................................",
  "20200217-12:0.last": "249",
  "20200217-12:0.total": "249",
  "20200217-13:1.hist": "...............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................",
  "20200217-13:1.last": "495",
  "20200217-13:1.total": "495",
  "20200217-14:2.hist": ".OOO............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................",
  "20200217-14:2.last": "976",
  "20200217-14:2.ooo": "3",
  "20200217-14:2.total": "976",
  "20200217-15:3.hist": ".OOOOOOOOOOOOIOOO................OOO...................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................OOO.OOO......OOO..OOO......................................................................................OOOOOOOO........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................OIIIOO..........OIOO..........................................................................................OOOOIIIOOOOOOOO..........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................OOO............OIOO..........................................................................................OOOOOOOO.OOO..OOO...................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................OIOO...............................................................................................OOOOOOI..OIOO.................................................................................................................................",
  "20200217-15:3.last": "4923",
  "20200217-15:3.ooi": "12",
  "20200217-15:3.ooo": "88",
  "20200217-15:3.total": "4923",
  "20200217-16:4.hist": ".IOOOOIOOOOOOOOOOOOOO.......II................OOO.........................OOO..OOO....................................................OOO..............OIOOOOO.......OOO...........II...........OOO.....OOO...............OIOOOO.........................................II.OOOO.........II....OOOO..OOOOO.........OOO..........OOO.OOO...............OOO...........................II.......OOO.....................OOO....OOO..............................OOO.........OOO................II......................II.............II.....OOO.............................II.........OOO...OIOO.........OOO...........OOOOOO...OOOOOO..............OOO..OOO.....................OOO............OOO.OOO...OOO...OOO.....................II..OOO.................II..........OOO...................................IOIIOO....OOO...........OIOO....OOO.........OOO..........OOO.......OOO..........................................................OOO....OOO...............OOO......II....II.......II..................II.....II..........OOO.............OOO.......OOO...............II.OOO...OOO...........................................II........OOO..........................................II..OOO...................OO.O........OOO.................................................................................................OOO...........................................OOO...OOO......OOO...............................................OOO...............OOO.......................OOO....OOO.......................................OOO..........................OOO...............OOO....II..........II.OOO.II....OOOO..................OOO............II................II...............II................OOO.........................OOO...................................................OOO......OOO............................................II....OOO.......OOO............OOIO.........................................OOO....II...........................OOO.........II.............II.....II...........OOO..........OOO........................................II............................II.........................I.I.............OOO.........OOO.......................................................OOOOIIIIIIIIOO...........OOO................................OOOO.........................OOO.OOOOOO...OOO..OOOII........OOO.........OOOO.OOOO........OOO......OOO........OOOOO...OOOOOO.......OOOOOOOO.......OIOO.OOO....OOO..............OOO.............OOO...................................................OOO..........OOO......OOO.......OOO..........OOO.............II...............OOO......OOO.........II........................................................................OOOII..OOO......OOO......OOO.....OOOOO.....................OOO....II..........................OIOO.....OOO....OOO.II.................OOO................................................OOOII.................................................................II.OOO..............OOO.......................OOO.........OOO......OOO.....OOO.......OOO...............................OOO.OOO...................OOO...OOO.....................................................IOOO.........OOO.................OOO..............OOO.......................................................................................OOO........OOOOO.......................................OOO...OO.O.....OOOOIIIIOOIOOOIIOO.........................II..................OOO......OOO.....OOO.............OOO......................OOO.....................OOO.......OOO..........II...........OOO..................OIOIOIIII.OO.....II..........................OOO................................OOO..........OOO...OIOO.....OOO.......................OIOO....OOO.OOO..................OOO...........................OOO...........OOO......OOO........OOO.............OOO........II......................OOO..........OOO.....II........................II...................OOIO..II.................OOO...................................OOO.............II.....II...........................OOO..........................................................................OOOOOO.................OOO...OOO......OIIOO........OOO.................OIOO...............................................II.....OOO............II......OOO.................OOOOIO.........II...........OOOOOOO...II......II.......................................OOO........OOOIOO..............OOIOOO.....OOOOOIOO..................II................II..............II.OOO.........II..............OOO.............OOO..........................OOO....................OOO............OOIO........OOO...........................................OOO.OOO...........................OOO..........................OOO.................OOO.OOO.OOO............OOO...OOO................OOO..............................OOO......................OOO.........OOO..........................OOOO........OOO...OOO.......OOO.............................................OOO...............OOOOIO............................OOO......OOO................OOO.OOO...........................................................OIOO............OOO.........OOO........OOO......................OOO.........OOO....OOO......................................OOO......OOO.OOIO....OOOOOO.....................OOO...............................OOO..........OOO.OOO......II..........OOO......II...................................................OOOOOO......................OOO.....................................................OOOIO....OOO....OOO...................OOO....OIIIIOOOO..........OOO..................OIIIOOOIIIIIIIOO........................OOO........OOO....OOO......OOO...............II...........................OOO...................OOO.....................OOO......OOO.......OOO..................OOO.OOO...OOO......OOOII......................................OIOO.........................................OOO.OOO..OO..O...............OOO....OOO...OOO...............OOO...........II......OOO.....................OOO...........................OOOIOIOO...........................OOIO..............OOO...................OOOOO.....................................OOIOO..........IIOOO..............................................................................OIOO.......................................OOO....OOOOOOO.......OOO................OIOOOIIOO....OOO......OOOO.....OOOOOO.....OOO..................OOO....OOO........................................OOO............OOO....IIOOO.....................OOO...........................OOOOOO.....................OOO.........OOO....OOO.........II....OOO............OOO.II........OOO..OIOO..........OOO......................................OOO......................OOO....OIOIO...................................OOO.............................II..........II.............................OOO...........OOIO.............OO.O.......I.I...........OOO..........OOO.OIIOO........OOO..........OOO......II.OIIIOO....OOO..........OOOIOOO...............OOO.........................OOO.........................................OIIIOIOOO................OOOO..........OOO.........II......................OOO........................................OOO..OIOO.....OOO.II..OOO.....OOO............II........................OOOOOOII.........................................OOOOOO.........II........................II...OOOOOO...................................OOO...OOO.......OOO......OOO.........II..OOO..OOO......II......................OOO.......OOO...OOO...............II....................OOO.OOO..............................................IOOO.............OOO.................OOOOOOO.............OOO............OIO.O...........OIIIOO........OIOIOO.O..........OOO.......II.OOOO.OOO.............OOO.................OOOII.............OOO.....IOOO.........OIOOOOO..........OOO...OOO...........................OOO..........................................II.....................II...OIIIOOOOOOOOOO..........OOO......OOO.............OOO.....OOOOOOOIOOOO............OOOOO....................................................................................OOO.......OOO.....................OOO...IOOO..........................OOO........OOO....................................OOO...........OOO..................OOO....................OOO............II....OOOIOOO.........................................OOO......OOOOOO.....................OOO...............OOO...............OIOO..........IOOO...........II..........OOO.OOO.....II............OOO.........................OOO..OIOOOOOO.......OOO.OOO..................OOO.................OOO.................OOO......................II..........OOO..........IOOO...OOO......................OOO......OOO......II.......III........................OIOO.......................OOO.....OOO.II......................................OIOOIOIIOOOO......OIOO.O....OOO........................................OOO................OOO.....OOO............................OOO.........OIOO....OOO....................................OOO.........OOIO....OIOOO....OOO.............OOO....................III..........O.OO............................................................OOO..............................OOOO.OOO..............II...................OOOOOO........II.............................OOO............................................OOO...OOO....OOO..............OOO...............OOO......................II....................................OOIO.O............OOO..........OOO............II....OIOO...........OOO............................OOO..................OOO.......OOO......................OOO........II............OOO.......OOO................OOO.....II.......OOO........II.....OOO.......OOO.OO.O................OOO.OOO........................OOOO......II..OOO............................OOO.....II.....II...................II.......OOOOOO........................................OOIO..................OIOO..........OOO......OO..O.........II..........................OOO.......OOOOOO.....II.............OOO..............OOO.......OOO............................OOO........OOO............OOIIIIIIIIIIIOOOIOOOIIIOOOIIIOOOIIIIIIIIIII.IIIIIIIIIIIIIOOOIIIIIIIIIIIIIOOOIOOOIIIIIIIOOOOIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIOOOIOOOIIIIIIIIII.IIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII.IIOOOIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIOOOOOIOOOOOOOOIIIIIIIIIOOOIIIIIIIIIIIIIIOOOIIIIOOOOOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIII.IIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIOOOIIIIIIIIIIOOOIIIIIIIOOOIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIOOOIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIOOOIIIOOOOIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII.IIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIOOOIOOOIIIIIIIIIOOOIIIIIIIIIOIOOOIII.IIIIIIIIIII.IIIIIIIIOOOIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIOOOOOIIIIIIIIIIIIIIIIIIIIIIIIIIOOOOIII.IIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIOOOIIIIIIIIIIIIIIIIOOOIII.IIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII.IIIIIOOOOOOIIIIIIIIIIIIIIIIIIIIIIIIII.IIIIIIIOOOIIIIIIIIIIIIIIOOOO.OOIIIIOOOI.IIIIIIIIIIIIIOOOO..OOIOOOIIIIIOOOOOOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIOOIOIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIOOOOOOOOIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIOOOO.OOIIIIIIIIIO..II.IO.OIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIOOOIIIIIIIIIIII.OOOIIIIII.IOOOOOOOIIIIIIIIIIIIIIIIIOOOIIII.IIIIOOIOIIOOOOOIOOOIIIIIIIIIII.IIIIIIIIIIIIIIIIIIIIIIIIIOOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIOOOIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIOOOIIIIOOOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIII.IIIOOOIIIIIIIIIIIIIIIIIIOOOIIIIIIII.IIIIIIIIIOOOIOOOOOOOI.IIIIIIIIIOOOIIIIIIIIIIIOOOIIIOOOIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOO..OOOOIIIIIIIIIIIIIIIIIIIIOOOOIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIOOOIIIII.OOOIIIIIIIIIIIIIIIIOOOIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIO..OOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOOOOIIIIIIIIII.IIIIIIIIIIIIIIIOOOIIIIOOOIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIO...OOIIIIOOOIIIIIOOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIOOOIOOOIIIIIIIIIIIIIIIIOOIOIIIIIIIIIIIIIIIIIIIIIIIIIOOOIOOOIIIOOOIIIII.IIIIIIIIIIIIII.IIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIII.IIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII.IIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIO....OOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIII.OOOIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIOOO.....OOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIOOOI.IIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIOOOIIIIOOOIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIII.IIIIIIIIOOOIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIOOOO..OOIIIIIIIIIOOIOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII.IIIOOOIIIOOOII.IIIIIIIOOOOOOIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIOOOII.IIIIOOOIIIIIIII.OOOOIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIII.IIIIIIIIIIIIIIIIOOOOOOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOOOOOIIIIOOOIIIOOOOOOIIIIII.IOOOIIIIIIIOOOIIIOOOIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIOOIOIIIIIIIIIIIIIIIIII.IIIIIIOOOOOOIIIIIIIOOOIIIIIIIIIIIIOOOIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIOOOOOOIIIIIOOOIIIOOOIIIOOOIOOOIIIIIIIIOOOIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIII.IIIOOOIIIIIIOOO.OOOII.IIOOIOIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIOOIOOO...OOOOOOIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIOOOIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIOOOOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIIIIIIIIIII.IIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIO...OOIIIOOOIIIIIIIIIIIIIIIIOIOOIIIIIIIIOOOIIIOOOIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIIOOOIIIIIIIIOOOIIIIIIIIIIIOOIOIOOOIIIIIIIII.OOOIIIIIIIIIIIIIIIIIIIIIIIIIII.IIIIIIOOOIIIIIIIIIIIIIIIIIOOOIIII",
  "20200217-16:4.last": "14438",
  "20200217-16:4.ooi": "4033",
  "20200217-16:4.ooo": "2228",
  "20200217-16:4.total": "14439",
  "20200217-17:5.hist": ".IOOOOOOOOOOOOOOOOOOOOOOIOOOOOOOOIIIIIOOOOOOOOOOOOIOOOIIIOIIOOOIIIIOOOOOOOOOOO.....II..OIOO...OO..OOOOOO.O......OOO.II..................OOO......OOO..................................OO.O.........OOOIOOO..OOO..............OOO......OOOOOOOO.....................OOOOOO.....OOO....OOIO.IIOOOO...........................OIOO......OOOOOO.II..OOO...OOO.II..IIII..OOOOO.OOOOO...........OOO.OOO..OOOOO.........OOO....OOO..........OIOOOOO.OOO..OOOIOO......OIOOOO.OOOOOOOOO....OOO.OOO............OOO....OOO.........OOO.....OOOOO..OOO...........II......OOIO...OOOOOO....O.OOOOO......OOO..........OOOOOOOOOOOOO....II..OOOIIII....OOOI........OIOO.....OOO.OOO.OOO........OOO.OOO.OOO...OOOOO..........OOO.OO.O............OOO........OOOOO........OOO........OO.O..OOO.OOOOO..............OOO......OOOO.............OOO..OIOOOOOO....OO.O....OOIO..........OOOO.O..OOO....OOOOOO...OOO.....OO.O...........................OIOO.OOO......II........OOO......OOO....OOIO..OOO..OOO.....OOO...OOO........................OOO........................OOO.........OOO.........OOOO..OOO......II....OOO.......OIOO........OOO...........................OOO......OOOO.....OOO.OOOOO.........OOO...OOO.OOO.OOOOOOO.OOO.......OOOII.OOO......OOO.OOOO.O.OOOOIOOOO..OOOO.O................OOO......OO.OOIOO.............OIOO......OOOOIOOIOOOOOO.........OOO.OO.O.OOO..OO.O.............OOO.OOO...OIOIIO..OOO...OOOOOOOOOO.OOO......II....OOO.OOOIOOOO.OOOOO..OOO.............O.OOOIIIOOO.OOO.......OOO............II.....OO.O...........II.OOO..OOO.........OOO...OOOOOOOOOO....OOOI....II.II..........OO.O.II...............OOO...OOO..OOO.OOOOOIOOO....OIOO......II.....OOO.....OOOOO.....OOOOIOO......OOO.........OOOIIOOOOO...OOO......II.OO.O.OOO..OOOO.O.........OOO........OOO......IIOOO.OOOOO.......OOOOO..........OOO........II...OOOOIO........II.OOOOOOOOOOOOOOOOO.OOO..OOOOOOOOO.OOO...........OOO..OOOO.O.OOO.II........II..OO.O......OOO.OOO.....II...............OO.IO...............II.OOOIOO.......OOO.............OOO..OOOOO...........OOOO.....OOOO.OOO....OOO...OOO......OOO..OOO.OOO.OOOOO......II...OOOO............OIOO...........................OOO..OOO......OOO...OOO.......OOO....OOO...OOO.......OOO..OOO..OOOOOO...OOO......OOO.OIIOOII..........II.IIOOOOO.......OOOOOOOO....OOO....OOOOOIOOOOI.OOO.OOOO.OOOOO...OOIO..................OIO.O.OOO.OOO.OOOO.....OOO..........OOO....OOOOOO..........................OOO.II..OOOOO.....OOO...OOOO.OOOIIOOO......II..OOOO.O....IIOOIIO...OOO.......OOO......OO.O...OOOO.OOOO.OOOOOOOO.O.OOO......IIOOO.....OOOOOOOO.....OOO..OOO.OOOOOOIOO...OOOOO......OOOO.O..OOO.OOOII....OOO.OOO.......II.OOO.OOOOOO.II.....OOOO......OOO...OIO.O....OOO...OOIO........OOO.....II...OOIO...OOO....OO.IOII...........OOO..OIOOOOOOO.OOOOOO..II.........................OOOO.OOO....OOOOO...IOO.O.OOOIIOOO.II.......OOO.OOOOOO....OOIOOIO...OOOOO.O...OO.O...........OOO...OOO.OOO.......OOO.........O.OO....OO.O.....OOO............................OOO.OOO.OOO......................IOO.O.OOOOOOOOOOOO...OOO.......OOOOOOO.......OOOOO..OOO..............OOO.......OOOOOOOOO.OO.O.......OOOO....OOO.OOIOOOOO...OOO....IOOO........................IOOOOO......OOOOIOO....OOOOOO.....OOIO.....OOIIOOOOIO......OOOOO....II..OOOOOOI..OOOOO.OOO........OOO............OOOOI......OOO.OOO.OOO..OOO.....OOO..OOOOOOOOOO.OOOO.........OIOO...IIII........II..OOO..II......OOO......OOO....OOO...OOO.OOIO......OOO.........OOOOOO.....OOO.......II.......II.OOO...OOOOOOO..OOO.OOO........OOO........OOO.OOO...II..........OIOOO.O....OOO.II...............OOO...OOOOOII....OO.O...OOO...OOO.OOOOOIO............................OIOO....OOOOIO..OOOOO.OOO...II...II.OOOIOO.OOIIOOOOOOOII.....OOOOIOOO.OOOOOOOOIOOOOO.OO..OOOOO...II...OOO.........III........OOO...OOO.OOOOOIOO.I.I...OOOOOIOO......OOO..OOOOOOO..IOIOO............II..OOO...OOOOOO..OOOOO....OOOOO.II..OOOOIO.....OIOO.OOO...OOOOOOO.IIOO.......OOOOO.OOOOOO.OOO......OOOOO.II.II.....OOOIII..............OOO..OOO.....OOOOO.O......OOOOOOOO..........OOIOOOIOOOOOOOOOO.OOO..OOO...........OOO....OOO....OOOOOO.OOIO....II.OOO...II............OOO.......OOO.....OOOOOOOIOOO.IIOOO..OOOOOO.....OOO...........OOO....OIIIOOOO.IIOOO....OOO..OOO....OOO...OOO...II..............OOO..OOOOOOO..OOO....II......OOO.OOOII..OOOOO..........OO.O.OOO.II..IIOOO..OOO....IIOO.OOOOIO.O.OO.O...OOO....OOO.......IIOOO..OOO.O.II.O.OOOOI..OOO.OOOOOOOI.....II.......OOO.O...OOOI.OOOOOOOOOOOO.OOO....II..OOOI..OOOIIII...........II..IIOOO................OOO.....IIOOO....OOO.OOO.........OO.O.....OO.O..OOO......OOOOOO................OOO.....OOO...II..............OOO.....OOO........OOO....II..OOO..II......OOIOOOIO.II.........OOOOOO...IIOOO....OOO........OIO.OOOOO.......OOO.........II.............OOOIIII.OOOOO....II....OOIO.....II.....OOOOO....OOOOO....OOOOOOIOOOOOOOOOIO....OOO.....OOOOOO.OOOOOO.....II...........OOO..OOOOOOOOO.OOOOOOOOO........OOO....II..OOO..OOOOO....OIOIO..OOOOO.O.....IOOO..II.OOOOOOOOOOOOOIOO....OOO..OIOOIOOOOOOOO.OOO..OOOOOO..II.....OOOOOOO.................OOO.OOO....OO.O...OOO.OOO..OOIOOOOOO.OOO...OOOOIOOIOO..OOO.OOO..OOO....OOOOO.OOOIO.....IIII..OOO..OO.O.OO.O.................OO.OIIOIOOOOIOIIIIIOOOO.........II............OOO......OOO....OOO......OOOOOO...OOO..OOO.OOOOOO......OIOO..OOO.II.......OOO....OOOOO.OOOOO.........................OOIOOOOO...OOIOOIOOOO.....OOO...OO.O.....OOOOOOOOOOO....OOOOOOOOOO...OOO..OOO.........OIIIOOOO.OOOOIIOO.II.OOO.OOO....OOOOOO.....II......IIOOO.OOO.O....OOOOO.O.....IIOOIO...OOO...OOOOOO....OOOOOOOO......OOOOO....OOO....II........................OO.O...OOO........OOOO..IIOOO...OOO...II............OOO............OOO....................OOOOOO...OOOII..OOO..............IIOOO.....II....II.................II..................OOO.OOO......II......OOO.....OOOO..OOOOOO.OO.O..OOO.OOO......II........II........II...OOOOOOOO....OOO.........OOOOOOI..OOO......OOO....II.OOIOOIIOOOI...........OOO....OO.O......OO.O..OOOOO...OOO...OO.O...............OOO.........II.....OOO.II.II..........OOOOO....OOO.........OOO...OOOOOOOOIOOOOO.O.....OOO.......OOOIIII.OOOO........OOOOO..OO.O.OOOO.OOO....OOOO.O...........................OOO......OOO......OOO.....OOOI.....OOOI..II...........OOOI......OOO.......OOO....OOO........OOO......OOO...OO.O...OOO....OOO..OOO..OOO.....OOIO.....OOOOO...OOO....OOO.OOO.....OOOOO.O..OOO.OOO....OOOOOOOOOOOOII.........OOOOIIOI..OOOO.O.....OOO...OOO..OOOOOO...OOO.......................OOO......OOO..................OOOOOO...................OOO.....OOO.OOOOO.......OOO....OOOOOOOO..OOOOO..OOO.....II..OOOO....OOO.OOO...OOO....II.....OOO..OOO.II.OIOOII..OOOOOOIIOOI....OOOII.........OO.O.II.OOOOOO..............OOO.OO.O.OOO....OOO.....IOOOOO...............OOOOO.I.OOOO...OOOOOIIOOIOOOIO..OIOO.....OOIOOOOOIOOO........IIOOOOOOOO...OOO....OO.O..OO.O................OOO.........OOOOOOOO.O...OOO..OOOOOIOO....OOO...............OOO................OOO.OOO..OOO.........OOOOOOOO.......OOOOOOOOOOO.O........OOOOOOI.......OOO....OOOOOI.....OOOOOOO...OOIOIOOOOOOOO.OOO..OO.O...OOOOO......OOOO.O....................OOOOOO.....OO.O.OOO...OOO......II...........IIOOOOOO.......OOO.OOOOOOOOO.O.....OOOOO.O.....OOOOIO........OOO....OOO.............OO.OOOO.........OO.OOOOO.O.........II.OOO...................OOO.....IIOOO..........OOIO...OOOII.....III....OOOOO........OOO............OIOO.....OOO...........OIOO..OO.O......OOOOO....................OOO....OOO......OO.O.OOOOOOOOOIOIOOOOO..................OIOO...II.OOOOIOOOO..OOO...OOOIOOO....OO.O.......OOOI...OOOOOO....OOOOO.OII...OOOOOOOOOO...OOO.OOO..OOOI.IIOO.O...II.OOO.O............OOO........OOO...II......OOO.OOO....II.OOOO.OOOOOIOOOOOO...................OOOOOO...OOOOO....II....OO.OII.OOO..II......OOO.OOO................OOOO.OOO...OOOOOOO........IOOO..OOOOOO.OOO..OOOOO.II........OOO.OOO.II..OOO.....OOO....OOO........................OOOOO........OOOOOO.OIOO..IIOOOOOOOI...OOO.....OOO.OOIOOOO..IIOOIO..............OOO..OOOOO.............OOOOOOOO.II..OOOOIOI...OOO.........OOOO.O.............OOO...........OOOOOO.OOOI.....II..............OOO..II.II.................OOO.OOO.................OOO...OOOOO.OII...OOOI.........IIIIII.OOO.OOO...OOOOOOO.....OOO...OOOO.....OOO.IIIIII..OOO...OOO.OOO.........OOOOOO...OOO.II...OOO..OOI.O.......OOIOOOO...OOOOOOOOOO..OOOOOOIO..OOIO..OIOOOIOOOOOOOO.OOOOOO.OOO.............OOOOO..IOOOOO....OOO.II......OOIOOO.......OOO..........................OOOOOOO......OOO........OOOI..OOO..OOOOOOIOO...OOOOOOOOOOOOOOIIOO.......OOOOOOOOOOOOO.OOO..OO.OOOOOO.......OOOOOOOOOO...OOO.OOO.OOO.OOOOO.........II..OOO.IIOOO..OOOOO...OOO..OOO.............OOO...........OIOOOOOOOIIOIOOOOOOOOOOOOOOIO...OOO...OOO......OOIO.OO.OOO.O....................OOIOOOOOOOOOOOO...II.......II........OOO.......OOO.OOO.OOOOOO...........OOO......OOOOOOO......OOOOO......OOOOOOOIOOOOOOOOOO......OOO..OOO.....OIOO..II.........OOO......OOIO..OOO.....OOOO...II.OOOOOO..OOO.........OOO.....OOO...OOO.....OOOOOOI............OOOOO.OOO...II.II.OOO........OOOOO.OOO........OOO.OOOI........OOO..OOOOOO.II......OOIO.OOO.....OOOOO.OOO.....OOO.OOOOOOOOO.OO..............OO.OOOOOOOO..........II.OOOOOOI..........II..OOO.IIII..........OO.OOOOOOO.II.OOOOO.................OOOOOOOOOOOOOOO......OOO.II....OOO.OIO.O.OOOOIOO..OOOII....OOO.................OO.O...OOO...OOO.......II..OOOI.OOO..OOO........OOO.............OOO......OOO....OO.O..................IIOOO......OOOO.....OOO.OOO.....OOO....OOO.OO.O...OOOOO..........OOO................OOO.OOOOOO........II..II..OOO.....IOOO..OOO.....OOOOOIIOOO.....OOO.......OOO................OOO...OOO...............OOOOO.........OOO.................OOOOOOOO..OOOOOOO....OOOOO.......OOO......II.....IIOIOO...OOOOOIO.OOOOOOOO..OOOOOOIIOOOOOOOOOO.II..OOOOOOO.OOOOOOOOOO..OOOOOOOO.......OOOI.OOOO..OOO.OOOOOOOO..OOOOOOO..OOO....IIOOO..OOOOO.............OOOOOOOO.OO.O.OOOOII......OOO....II.....OO.O..OO.O..IIOOOOO.......OOO.....OOOII.OO.O...............OOOOOOOOOO.O........OOOOOOIIOOOOO...OOOOOOOO....OOOIOOOOOOOOOOO.............OIOO....OOO.....OOO...................OOO.............OOO.................OOOII.OOOOO.O.....OOO.....IOIOOOOO........OOO..OOO.OIOOI..OO.OOOO..OOOO.OOOO......OIOO.OOO..OOO.OOO....OOOOIOO..........II..OIIOO...IOOOOOO.OOO.......OOO..OOOOOOIIII...................II....OO.O........II.OOO..OOOOOI......OOO.......................OOO...........II...III.....................OOO.......OOO...OOIOIIIOOOO.IIOOOOO........OOOOO.......OOOOOO.OOOIIOOOIOOOOOO..............II...OOO...............OOO.OOOOOOO...II........OOOOOIO..............OOOII....OOOOO.I.I.II..OOO..II.........OOOO.O.......OOO....OOOOOOO.OO.OOOO.OOO.OOOOOOIII....OOO................II..OIOO...OOO......OOOOOOOOO.O....OOOOOIO..OOO..II..OOOOOOOOOOO..OO.O..OOOIIOOI.OOO..OOIOIIOOOOO.II.OOOOOOOIOOOIO..OO.OOO.O.....IIIIOOO..OOOO.OOOO...II..OIOOOOIOOOOOO.OOO.......II.OOO..II....OOOOO..IIII..OOOOOIOO.....OOOOOOOIO.OOOOIOOOOOOOOO..OOO..OO.O...OOO.....OOOOOI.IIOOOOOOOOOOOOII..OOOOO..O..OOOOOOO..II.OOO..IIOOOOOOOOO.......................OO.O...OO.O........II.OOO..OOO....OOOOO.........................OOOOO...OOOOO......OOO.OOOOOO..OOOOOI...OOO.OOOOOII..OO.O..OOO...OOO...OOOOOOOI.......OOO.................II...II...OOOO.OOOO.......OOOOOO.II...OOO..OOOOOOIO.OOO......OOO.......II...OOO.OOOOO.O..OO.O....II............OOOII.....IOOOO.O...OO.O..OIOOOOO.............IOOO....OOOOOO.OOO...II..OOO.....OOO....OO.O.OOO..........OOOOOO..OOO...II................OOO.......OOO............OOO..OOO....OO.O.........OOO.II....OOO....II.OOOO.........OOO....OOO......OOO.......OOO..OOO...........OOO.............OOO...............................OOOOO.O..II..OO.O....OOO.........II..OOOOOOOIO...........OOO.OOIO....OO.OOOOOI....OO.O.OOO.OOIOI.OO.O................OOOOO...OOO...OOO....II...OOOIOOO.OOOO.IOOO...............OOO.IIOOO..IIOOO.OOOOOOOII..OOO.....II.OOOOO....OOOOOO........OOOO.O...OOOOOOIOOIO..........OOOOOO.OOO.OOOO.OOO.IIOOOOO....OOOOOOO..II.............OOO.......O.IIIIIIOO....OOOOOOO.OOO....OOO....OOO..............OO.O.....OO.OOO.OOOO...................OOO....IIOOO.OOO..OOO..OOO..II.OOOOOOOOOOOO.....OOOOOOIOO..OOOI.............OOO........OOO....II.....IIIIII....IIOOO..II...............II.............OOOOOOO.II...OOOI....................OOO...OOO.........IIOOO......OOO...OO.O.......OOO...OOO...OOOOOOOIOOOO.................OOOII...............OOOOOO.......OOO............OOO....OOOO.O.....OOO..............OOO..OOO..II...........OOOOOO.................II.OOOOO...OOOO....OOIOOO........OIOO...II...OO.OOOO..II...OOO....OO.O...OOO....OO.O.OOO.OOO.........................II..OOOOO..OOO..OOIO.....OOO........OOO.OOOOO..OOO...........II........OOOOO.OOOI........OOO...II.II...........I.I...OOO.....IIII.........OOOOOIO......OOO....OOO...II.OOOOO......OOOI......OOO...OOO....OOOOO.OOOO.OOOOOII...OOO.OOO..II...OOOOO...OOOOIIOO................OOOOO.......OOO....II...OOOOO..........OOO.OOOOOOO.OOO.....II....OOO...OO.O......OOO................................IIOOOOOO.OOO..OOO...........OOO.......IOOOOOOOO............IIOOOOOOOOO....OOO.OOOOO.O......OOO......II.OOOOOOOO..OOO....OO.O...OOOOOOOO.................II..OOO....OOO.........IIOOOII.........OOOOOOOOO...OOOOOOOO.OOO.OOO......II..................OOOOOO.....OOO........OOOIOOOOO...OOOI.OIOOOOO...OO.O....OOIOOOOOO...............OOO......OOO........OOOOOIO.....................OO.O.........OOIOOOO.OOOOOO.......OOOOO..............II..........OOO.....OOO................OO.OOOO.........OOO......OOOOOOO.OOO..OO.O.......OOOOOO....OOO..........OOO......OOOOOOO.OOO.............OOO..........II.II......OOO....OIOOOOO....OOO.OOO..........OOO...IIOO.O..........OOO..IIIOOO.......OOO..OOO..OOOOOO....OOO...OOOOOOOOOO...OOO.....II...OIOIO..OOO......OOO....OOOOO..OOOOOOOOO.....OOOOO.........OOIOOO.............OOO..OOO..II...........OOOO.O.......OOO..OOO..........OOO..IOOIO........OOO...................OIOOOOOOOOOO...II..OOOOO.....OIIOIO",
  "20200217-17:5.last": "13645",
  "20200217-17:5.ooi": "909",
  "20200217-17:5.ooo": "5339",
  "20200217-17:5.total": "13645"
}

Of course I’m kidding! Here’s the percentage of out of order / out of index messages depending on the rate of TX.

And here is a distribution “lateness” of messages. Lets just look at two cases, feel free to dig into the notebook for the details. The two plots below show 2 msg / sec vs 100 messages / sec.

As you can see, everything as one would expect. The faster the messages come in, the bigger the percentage of out of order / index. The lateness is still pretty OK though, most are in their right position and about 10-15% of messages are out of place. Note that 15% out of order messages being off by 1 lead to 30% out of order messages (just consider the sequence 1,2,4,3,5 which has 1 late message but 3 our of order messages (4,3,5).

It should also be noted that the size of the message has an impact on the average lateness as well as many other factors such as number of recipients, senders, geographical server locations, etc. If your business case depends strongly on the lateness, you should run a similar experiment with your unique case and infrastructure. Happy to help with that btw ;-)

Synthesis of things learned

Order becomes increasingly hard to trust, the faster the messages come in. If the consumer is too slow in handling messages, timeouts and retries make it even harder.

10 messages per second are still mostly in order. 50+ messages per sec on the other hand show plenty of out of ordering events. But most can be caught by waiting 2-3 messages.

100 msg/sec have ~10% messages late by 1 and 1% messages late by 2. There is a long tail of messages late by n.

One has to evaluate the individual use-case to decide how long to wait for missing messages before going ahead with the calculation with missing values. It really depends on the use-case but it’s nice to see that the extend of the lack of order can be evaluated.

PubSub does some awesome auto-scaling magic behind the scenes. The fact that I could be served by 100s of forwarders without knowing or worrying about it is pretty nice.

Terraform for GCP allows me to build what is essentially enterprise grade cloud native infrastructure in a weekend. I’ve used it plenty on AWS infrastructure but the components on GCP just feel “higher level” than AWS. But 400 errors from the Google API in Terraform are sometimes hard to debug without TF_LOG=DEBUG set and looking at the HTTP responses / Docs

GCP API enabling as a first step is annoying and could(should) be made transparent. Ideally, an organization would take care of this at a project start level and this would be handled centrally. The GCP manager would enable the new project, assign the owner and enable all needed APIs for the team.

Redis is a pretty cool technology, given that you cannot have state. However, the performance is still network I/O bound. Things like the atomic getset operator remind me of the computer science 1 & 2 lectures where one tries to really optimize for performance.
